5.2-41
005.050.01-EN
4b. The receiver display shows the following
message:
(communication by cable)
Make sure step 4 follows step 3
within the first few seconds.
5. When pairing is in progress, the display of
the receiver shows the message:
(ID programming active)
At the same time, the screen of the VEC-
TOR control displays the message R 13 M
"Pairing in progress"
6. Wait until the buzzer in the transmitter
sounds 10 times. This is to confirm that the
pairing process was successful.
The pairing process lasts about 15 sec-
onds. Thereafter, the transmitter shuts off
automatically.
7. If transmitter and receiver are paired for the
first time, the transmission of data for the
transmitter display is necessary.
In this case, the transmitter display shows
the transmission progress (Fig. 1).
During transmission, the receiver display
(Fig. 1) shows the message:
(communication by cable: identification
(ID code) required)
Fig. 1
