The fault is displayed on the screen and an-
nounced by the buzzer in the control cabinet.
• Activate "QUIT" on the remote
control box (Fig. 1) once.
The buzzer stops sounding (if
not switched off manually, the
buzzer will be stopped auto-
matically after 60 seconds).
The message continues to be
displayed and can be read
without hurry.
• Depress the "QUIT" key on the
control cabinet (Fig. 2).
The fault message is definitely
acknowledged.
The message is deleted from
the display and logged in the
faults list.
ATTENTION:
RISK OF ACCIDENT AND DAMAGE
After shut-off by a high- level fault,
the control system and, if applicable,
the drive engine must be restarted.
• It is absolutely vital to have a
severe fault rectified before re-
starting. there isOtherwise the
risk of irreparable damage to the
machine.
Important:
Severe faults can only be acknowl-
edgedwiththe"QUIT"keyonthe
control cabinet irrespective of the
selected mode LOCAL or REMOTE.
6. Mode of operation : REMOTE
diagnosSilent tic : Yes
Severe fault
In addition, the control system goes to e-stop
mode.
Optional shutdown of the engine is also
possible.
• The LCD window on the Radio remote will have
abbreviated codes which are explained in Figure 3.
NOTE:
Cable remote has no LCD window.
30
3
6
23 4
8
30 356 534 C
5
4
3
2
1
0
10
9
8
7
6
1
2
3
HOME HE LP
CLEAR ENTER
OFF
QUIT
+
-
START
OK
1
0
2
3
PTO
Menu: [ENTER]=ON
1500 rpm
62˚C
x1000
QUIT key
QUIT switch
Fig. 1
Fig. 2
VECTOR REMOTE DATA ABBREVIATIONS
PTO RPM (all digits are numbers)
HYD. PRESSURE IN BAR
=
STROKES/MINUTE=
HYD. OIL TEMP (Degrees Celsius)=
NO DATA SEND=
HOPPER GRATE OPEN=
PUT SWITCHES TO NEUTRAL
MACHINE IN CLEANING MODE
=
MACHINE in LOCAL MODE=
MACHINE in RAM CHANGE MODE=
MACHINE in TEACH MODE
EMERGENCY STOP ACTIVATED
=
START CONTROL SYSTEM=
WATER TANK LOW=
=
=
=
30364527
Fig. 3
