Service Manual
32
V
ECTOR
C
ONTROLLER
-S
ERVICE
M
ANUAL
D04L
PTO RPM-Limit exceeded !
D05L
Indicator-Switch
PTO = ON/OFF
Fault !
D06L
Indicator-Signal
Engine Load
Fault !
D07L
Indicator Lvel
Diesel-Reservoir
Fault !
D08L
DO31
Disconnected
Truck Interface
Diesel Start - D031 !
D09L
DO31
Overload
Truck Interface
Diesel Start - D031 !
D10L
DO32
Disconnected
Truck Interface
Diesel Stop - D032 !
D11L
DO32
Overload
Truck Interface
Diesel Stop - D032 !
D12L
DO33
Disconnected
Truck Interface
RPM (+) - D033 !
D13L
DO33
Overload
Truck Interface
RPM (+) - D033 !
D14L
DO34
Disconnected
Truck Interface
RPM (-) - D034 !
D15L
DO34
Overload
Truck Interface
RPM (-) - D034 !
31
33
Table of Contents
Table of Contents
3
Commissioning
4
Selecting Local Control
5
Selecting Remote Control
6
Selecting Ram Change Mode
7
Emergency Stop Buttons
8
Override of the E-Stop Manifold
8
Options Box
9
Control and Monitoring Components
10
Menu Control
11
Local Control
12
Remote Control
13
Menu Overview - Main Menu
14
Menu Overview - Submenus
18
Menu Operation - Example
19
Diagnostic System/ "Fault Handling
20
Acknowledging Faults
22
Fault Definition
22
Summary of Messages
30
