5
speCIfICaTIons
41.3” (105cm)
21.4” (54cm)
55.6” (141cm)
Before Assembly
Select the area where you are going to set up and operate your machine. For safe operation, the location must be on a
hard,levelsurface.Allowaworkoutareaofaminimum90”x70”(2.3mx1.8m).
Basic Assembly Tips
Follow these basic points when you assemble your machine:
1. Read and understand the “Important Safety Instructions” before assembly.
2. Collect all the pieces necessary for each assembly step.
3. Using the recommended wrenches, turn the bolts and nuts to the right (clockwise) to tighten, and the left (counter-
clockwise) to loosen, unless instructed otherwise.
4. When attaching 2 pieces, gently lift and look through the bolt holes to help insert the bolt through the holes.
5. The assembly can require 2 people.
Maximum User Weight: 300 lbs. (136 kg)
Power Requirements:
OperationalVoltage:9VDC
Operating Current: 1.5A
Regulatory Approvals:
ISO 20957
ACPowerAdapter: ULlisted,Rated120V60HzInput,
9VDC,1500mAOutput.Class2.
!
This product, its packaging, and components contain
chemicals known to the State of California to cause
cancer, birth defects, or reproductive harm. This Notice
is provided in accordance with California’s Proposition
65. If you would like additional information, please refer
to our website at www.nautilus.com/prop65.
