Schwinn 26” - Page 25

22
Evenspace
between wheel
and fork
axle nut
Note: If you run out of
adjustment capability on one
side, adjust the screw on the
opposite side. If you run out of
adjustment capability on both
screws do a minor adjustment to
the brake cable. Adjustments
should be made to each side as
equally as possible to prevent
running out of adjustment
capability. See Adjust the
Brake Cable) and repeat steps
four through six.
5
1
Evenspace
between brake
pad and wheel
2
Wheel is centered
3
4
brake arm screw
brake arm
screw
Brake
pads are
centered on
each side of
the wheel
