ASSEMBLY INSTRUCTIONS
8
Step 2 Install front stabilizer and Extrusion Assembly
Parts:
• Front Stabilizer (Ref E)
•ExtrusionAssembly(Fromstep1)
•MainUnit(RefA)
Tools:
•SuppliedAllenWrench
2-1 AttachtheFrontStabilizer(RefE)totheMainUnit(RefA)using
twoM8x25atheadscrews(Ref2)andcompletelytightenthe
hardware.
2-2 AttachtheExtrusionAssemblyfromStep1totheMainUnitusing
fourM8x25atheadscrews(Ref2)andcompletelytightenthe
hardware.
2-3IfExtrusionAssemblyisabovetheoor,standwithbothfeeton
thetworearextrusionsforapproximately20seconds,stepoffof
 theunit,andthenadjustfootpad(refQ)underextrusion
assemblyuntilitjusttouchestheooronbothsides
A
E
2
2
2
Q
Q
