ASSEMBLY INSTRUCTIONS
Step 3 Install Console Mast
Parts:
• Console Mast (Ref K)
•MainUnit
Tools:
•SuppliedAllenWrench
3-1 ConnectthewireharnessfromtheMainUnittothe
wireharnessintheConsoleMast.
3-2 SlidetheConsoleMast(RefK)downontotheMainUnitand
secureusingsixM8x15Lbuttonhead(Ref1),sixM8washers
regular(Ref3)andsixM8washerslocking(Ref5).
NOTE:Becarefulnottopinchthewireswhenslidingthe
ConsoleMastontotheMainUnit
K
1
3
5
