ASSEMBLY INSTRUCTIONS
10
Step 4 Install Console Handlebar
Parts:
•ConsoleHandlebar(RefD)
Tools:
•SuppliedPhillipsHeadScrewdriver
4-1 FeedtheWireHarness(RefW1)fromtheMast(RefK)andthe
ContactHeartRateWire(RefW2)fromtheConsoleHandlebar
throughtheholeintheConsoleHandlebar(RefD).
4-2 SecuretheConsoleHandlebartotheMastusingfour
M5x10Lphillpsscrews(Ref8).
K
8
D
W1
W2
