ASSEMBLY INSTRUCTIONS
Step 9 Install Upper Handlebars
Parts:
•RightUpperHandlebar(RefP)
•LeftUpperHandlebar(RefO)
Tools:
•SuppliedAllenWrench
9-1 SlidetheUpperLeftHandlebar(RefO)intotheLowerLeft
HandlebarandsecureusingfourM8x15lbuttonhead(Ref1)
fourM8washersregular(Ref3)andfourM8washerslocking
(ref 5).
9-1 RepeattheprocedurefortheUpperRightHandlebar(RefP).
P
O
3
5
1
3
5
1
