ASSEMBLY INSTRUCTIONS
14
Step 8 Install Right and Left Foot Assembly
Parts:
•FootMountPlateQty.2(RefT)
•RightFootAssembly(RefC)
•LeftFootAssembly(RefB)
•ArmCotterPin(RefN)
Tools:
•SuppliedAllenWrench
8-1 SlidetheshaftundertheLeftFootAssemblyintothePivot(RefP1)onthe
LeftLegAssembly.AlignaFootMountPlate(RefT)withthePivotand
FootassemblyandsecureusingoneM8x20Lbuttonhead(Ref11),
twoM8x15Lbuttonhead(Ref1),threeM8washerslocking(Ref5)and
threeM8washersregular(Ref3).
8-2 PositiontheLeftFootAssembly(RefB),markedwithan“L”,inthe
UbracketatthebottomoftheLeftLowerHandlebar(RefM).Inserta
CotterPin(RefN),fromtheinside,throughtheUbracketandFoot
AssemblyandsecurewithoneM8x20Lbuttonhead(Ref11)one
M8washerregular(Ref3)andoneM8washerlocking(Ref5).
NOTE:
 1.MakesureKeyonCotterPinengagestheSlotintheUbracket.(see
 detail).
 2.MakesuretheM8x20bolt(Ref10)staysconcentricwithCotterPin
 (RefN),andthenusetooltotightenthebolt(Ref10).
8-3 RepeattheprocedurefortheRightFootAssembly(RefC)marked
withan“R”.
C
B
M
11
1
11
3
N
1
5
P1
T
Key
Slot
Detail
5
3
