ASSEMBLY INSTRUCTIONS
Step 7 Install Right and Left Lower Handlebars
Parts:
•ArmPivotRod(RefL)
•RightLowerHandlebar(RefQ)
•LeftLowerHandlebar(RefM)
Tools:
•2SuppliedComboWrenches
7-1 SlidetheArmPivotRod(RefL)throughtheConsoleMast
(Ref K).
7-2 SlidetheRightLowerHandlebar(RefQ),markedwithan“R”
sticker,alongwithoneM8wavewasher(Ref12)ontotheArm
PivotRodandsecureusingoneM8x20Lhexheadthreadlock(Ref
10)oneM8washerlocking(Ref5),oneM8washerwide(Ref4).
7-3 RepeattheprocedurefortheLeftLowerHandlebar(RefM)
markedwithan“L”stickerthatcanberemoved.Usethe
twosuppliedcombowrenchesthoroughlytightenthehardware
7-4 PlaceaRoundCover(Ref6)overtheheadofeachbolt.
Q
6
6
10
5
12
M
L
K
4
