Schwinn 430 - Step 11: Remove Hardware from Console; Step 12: Connect Cables and Attach Console

18
11. Remove Hardware from Console
NOTICE : Do not crimp the cable.
Note: Hardware is pre-installed and not on the Hardware Card. *
5
*
X4
#2
12. Connect Cables and Attach Console to Frame Assembly
NOTICE : Align the clips on the cable connectors and make sure the connectors lock. Do not crimp cables.
#2
*
X4
