Schwinn 430 - Parts List

6
A decal has been applied to all right (“ R ”) and left (“ L ”) parts to assist with assembly.
Item Qty Description Item Qty Description
1 1 Console Mast 12 1 Upper Shroud
2 1 Static Handlebar 13 1 Front Stabilizer
3 1 Arm Pivot Rod 14 1 Right Leg
4 1 Water Bottle Holder 15 1 Right Pedal
5 1 Console 16 1 Shroud Cap
6 1 Upper Left Handlebar Arm 17 1 Lower Right Handlebar Arm
7 1 Lower Left Handlebar Arm 18 1 Upper Right Handlebar Arm
8 1 Left Pedal 19 1 AC Adapter
9 1 Rail Assembly 20 1 MP3 Cord
10 1 Left Leg 21 1 Manual Lift Assembly
11 1 Frame
22 1 Silicone Lubricant, Bottle (not shown)
PARTS
1
4
6
5
2
3
12
7
8
10
11
9
16
14
13
18
17
15
19
20
21
