Schwinn 430 - Hardware and Tools Required; Tools

7
Item Qty
Description
Item Qty
Description
A 6 Button Head Hex Screw, M8x16 (with
Loctite
®
adhesive)
F 6 Wave Washer
B 4 Flat Washer, M8 G 12 Lock Washer, M8
C 8 Wide Washer, M8 H 2 Pivot Sleeve
D 4 Button Head Hex Screw, M8x16 I 2 Cap
E 2 Hex Head Screw, M8x20
HARDWARE / TOOLS
Tools
Included Not Included
6 mm
(recommended)
#2
13 mm
15 mm
19 mm
A B C D E F
G H
I
