A decal has been applied to all right (“ R ”) and left (“ L ”) parts to assist with assembly.
Item Qty Description Item Qty Description
1 1 Frame 10 1 Pedal Arm, Right
2 1 Front Stabilizer 11 1 Pedal Arm, Left
3 1 Water Bottle Holder 12 1 Lower Left Handlebar Arm
4 1 Console 13 1 Lower Right Handlebar Arm
5 1 Console Mast 14 1 Upper Left Handlebar Arm
6 1 Leg, Left 15 1 Upper Right Handlebar Arm
7 1 Leg, Right 16 1 Static Handlebar
8 1 Rail Assembly 17 1 Media Tray
9 2 Pedals
Note: Media Cable is attached to the Console.
