9
3. Connect the Console Cable
NOTICE: Align the clips on the cable connectors and make sure the connectors lock. Do not crimp the Console Cable.
5
5
4. Attach Console Mast to Frame Assembly
NOTICE: Do not crimp the Console Cable.
