Schwinn IC3 - Battery and Belt Maintenance

23
Replacing the Console Batteries
When the batteries are low on power, the console display contrast will dim.
Whenreplacingthebatteries,makesurethebatteriespointinthe+/-directionshowninthebatterybay.
Note: The console uses AA size alkaline batteries (SUM3)
!
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (Ni-Cd, Ni-MH, etc) batteries.
Besuretoremovethebatteriestopreventcorrosiondamageifyouarenotgoingtousethemachineforanextended
period of time.
+
-
X2
Checking the Drive Belt Tension
TotesttheDriveBelttension,sitonthebikeandusethepedalsatapproximately20RPM.Thenacceleratequickly
(speedburst)toyourmaximumabilityandfeelwhethertheDriveBeltslips.Ifthepedalsmovenormallywithnoskipping
(slip), the tension is correct. If the Drive Belt slips, refer to the “Adjust the Belt Tension” procedure in the Service Manual.
