Schwinn IC3 - Assembly Instructions; Attaching Stabilizers; Seat and Handlebar Installation

9
1. Attach Stabilizers to Main Frame
Note:Thehardware(*)ispre-installedandnotintheHardwareBag.Ifatubeispre-installedinthestabilizerbracket,
remove and set it safely aside.
ASSEMBLY
2. Attach Seat to Seat Post and Frame
NOTICE: Make sure the adjustment knob (4a) engages the holes in the Seat Post.
1
2
3
*
*
*
X4
5
4
A
B
4a
