Schwinn IC4 - Install Handlebar Assembly

10
4. Install the Handlebar Assembly to the Frame Assembly
NOTICE: Make sure the Adjustment Handle engages the holes in the Handlebar Post. When fully tightened, the Handlebar
Adjustment Handle must point forward.
5. Attach the Water Bottle Bracket and Holders to the Frame Assembly
3mm
*
3mm
X4
X4
10
12
10
*
13
A
B
