Page 4
637-8808 Rev. J
6. Ensure that the fore/aft adjustment lever
is closed, then use a torque wrench with a
11mm deep socket to tighten the fore/aft
lever adjustment nut to 4 Nm (2.95 Ft-Lbs).
7. Reinstall the seat slider and locking screw
from Steps 1+2. This will conclude the
procedure - DO NOT CONTINUE TO STEP 7.
8. With the fore/aft adjustment lever open,
tighten the adjustment lever nut 1/4 of a turn,
then close the adjustment lever and check
the function by reinstalling the seat slider
removed in Step 2 and pushing backwards
on the seat slider - it SHOULD NOT move.
9. Repeat Step 7 as needed until the seat slider
is tight. This will conclude the procedure.
Fig. 5
