Page 5
637-8808 Rev. J
Handlebar Slider
1. Flip the fore/aft adjustment lever up.
Fig. 6
2. Move the handlebars forward until the fore/
aft adjustment lever nut is visible through the
hole on the underside of the handlebar post.
Fig. 7
3. Use a ratchet wrench with a 11mm deep
socket to remove the 1/4” nylock nut and
M6 flat washer, then remove the adjustment
lever.
Fig. 8
