2.0 Packing List
I
f the outside of the shipping packaging is damaged, notify your shipping
department immediately. The shipping department may wish to notify
the carrier at this point.
If the shipping carton is not damaged, carefully remove and identify all of
the components as listed below. If any of items are missing, contact
Scientifica Ltd. Please retain the packaging for storage or future
transportation of the system.
• Sample plate
• Locking ring
• Break out box
• 25 Way to 25 Way lead
• USB Cable
• Digital Vernier Caliper
• 1 x Screw Kit
• Hex Key set
• 10 mm Allen Key
• (Optional) Z-focus module
• LinLab CD (section 8.0)
Top Plate
3 x Manipulator mounting
plates
Motorised XY Translation
stage
8x Leg bolts
(usually shipped
screwed into legs)
4 x Adjustable legs
2 x Feet
4 x Foot Mounting
Locks
1U Control Rack
