7.0 Specifications
Supply voltage range NA*
Supply frequency NA*
Power/current rating NA*
* indicates that this unit on its own is not functional and needs to be connected to a Control
Rack for normal operation
Number of axis 3 with virtual 4th axis
Travel 20 mm
Step size 0.1μm
Speed (minimum) 1μm per second
(maximum) 4 mm per second
Resolution 20nm
Memory Positions Up to 50 (unlimited via Linlab)
Bearings Crossed roller
7.1 Environmental Conditions
The PatchStar is designed to be operated and stored within the following environmental
conditions.
• For indoor use only
• Up to altitudes of 2000metres
• Between a temperature range 15°-40°
• Maximum relative non condensing humidity of 60% for temperatures up to 31°
