SCM CUBO2 SMART - General information and limits; Electrical details

OEM Manual – CUBO
2
SMART
Pag. 37
18 General information and limits
General Characteristics
Cubo2Smart line
UMTT 030 MT UMTT 045 MT UMTT 067 MT UMTT 100 MT
models
Refrigerant
R744 (CO2)
Compressor Toshiba
DY30N1F-10FU DY45N1F-10FU DY67L1F-10FU RY100L1F-10FU
Motor Rotary Compressor
Number of cylinders
1 1 2 2
Number of poles
4
Moto type
DC Brushless
Revolution range 25 ≈ 100 rps 25 ≈ 100 rps 25 ≈ 100 rps 25 ≈ 100 rps
Oil charged 520 ml 520 ml 450 ml 450 ml
Oil type
PAG VG100
Discharge working pressure
range 125 bar max 125 bar max 125 bar max 125 bar max
Suction working pressure range
12 ≈ 41 bar 12 ≈ 41 bar 12 ≈ 41 bar 12 ≈ 41 bar
Evaporating temperature -15 °C ≈ +5 °C
Susction Superheating 10 K ≈ 20 K
Discharge temperature max 130 °C
Ambient temp.
-15 °C ≈ +40 °C (Above 35 °C ambient, adiabatic option is required)
-20 °C only with winter kit option
System EC fans (max) In = 2,2A - P abs = 345W
Receveiver 2x 2,4 lt (2,4 lt Receiver max charge)
Suction line
3/8" K65 (9,52mm) 3/8" K65 (9,52mm) 3/8" K65 (9,52mm)
1/2" K65
(12,70mm)
Liquid line
3/8" K65 (9,52mm) 3/8" K65 (9,52mm) 3/8" K65 (9,52mm)
3/8" K65
(9,52mm)
PS Suction / Liquid 80 bar / 80 bar
PED Category I
Dimensions (AxBxH) 1150 x 617 x 803 mm
Generic Transport dimensions (AxBxH) 1300 x 700 x 950 mm
Gross weight 140 Kg
Transport way Pallet & Carton
Painted RAL 7035
Sound level (max speed)
1)
44 dBA 44 dBA 44 dBA 44 dBA
1) Sound pressure and sound power analytically calculated. Sound pressure level at 10 m in free field.
19 Electrical details
Electrical Information
Cubo2 Smart line Size
UMTT 030 MT DX UMTT 045 MT DX UMTT 067 MT DX UMTT 100 MT DX
Power Suply
230V/1Ph+N+PE/50Hz 400V/3Ph+N+PE/50Hz
Recommended protection Circuit Breaker Circuit Breaker Circuit Breaker Circuit Breaker
1+N C16A
1+N C20A
1+N C25A
3P C20A
MRA 11,6 A 16,1 A 23,1 A 17, 3 A
P abs max 2460 W 3500 W 5110 W 7900 W
MRA = Maximjum Rated Abs.
 Unit is made in accordance with EN-60204-1. All electrical cabling, in external unit, have been
made in accordance with EN-60204-1.
All connection must be done by qualified persons according to legal standards in force in the
relevant countries and to EN-60204-1. Supply cable must be connected on terminal of upstream
main switch. Connect wire of ground (PE), from specific terminal block to system protection.
