OEM Manual – CUBO
2
SMART
Pag. 8
4 Unit installation
The unit has been designed for outdoor installation.
Respect distances for correct operation.
In the case of several units in series or in parallel mode, respect the minimum distances for
properly maintenance.
In the case of several units in parallel, avoid the gas cooler air flow direct on second units but
install in order to have opposite air flow (see picture).
Minimum maintenance distances.
Minimum distances for GC air flow circulation
Vertical installation
Horizontal installation
Not permitted!
Installation in series (with opposite GC air flow)
