Scotchman DO-150-24M - Sheet Metal Parts & Hardware

18
221005 M6 X 12MM SHCS
1
2
3
4
5
6
7
8
9
10
11
12
13
1 033273 PUNCH COVER PAINTED
3
224205 M10 X 16MM WLCS
1 013289 SHEAR DOOR ASS'Y
1 341140 PIPE NOTCHER SLUG RAMP
2 204222 M10 X 55MM HHCS
2 214012 M10 REGULAR WASHER
1
013621 SLUG CHUTE1
013160 TOOLING SLUG CHUTE
1 033281 DO120, 135, & 150 CYL. SHROUD
1 033030 REAR SHROUD S/N: 1047M0108 AND UP
1 033157 NOTCHER GUARD PAINTED
1
1
033029 FRONT SHROUD S/N: 1047M0108 & UP
ITEM QTY. PART # DESCRIPTION
033196 REAR SHROUD S/N: 1046M1207 & PRIOR
13A
11A
FRONT SHROUD S/N: 1046M1207 & PRIOR 033195
1
9.8 SHEET METAL PARTS & HARDWARE
PAGE 106
14 1 033297 DO120-150 PUNCH PIN COVER
