Scotchman DO-150-24M - Installation and Set up; Physical Dimensions

4.0 INSTALLATION AND SET UP
CAUTION: THIS SECTION DISCUSSES INSTALLATION AND SET-UP PROCEDURES.
PLEASE READ THOROUGHLY BEFORE OPERATING THIS MACHINE.
►
PAGE 10
1
Floor to Punch Ram 45 114.3
2
Floor to top of Die Holder 40-1/2 102.9
3
4
5
6
7
8
9
10
Floor to Punch Bolster 34-1/2 87.6
Floor to Bar Shear 29-3/4 75.6
Floor to Tool Table 48 121.9
Height 77-1/4 196.2
Length 83 194.3
Punch Stroke 2.34 5.9
Width 38-1/2 97.8
11
Floor to Bottom Rail 3 7.6
INCHES CM DESCRIPTION
ITEM
Weight 6,404 LBS. 2905 KG
12
Notcher Table 30 76.2
4.1 PHYSICAL DIMENSIONS - SEE FIGURE 2
