Scotchman DO-150-24M - Upper Stroke Control Assembly

PAGE 98
9.5 UPPER STROKE CONTROL ASSEMBLY
1 033707 D.O. STROKE ASS'Y1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
1 007711 STROKE COVER - INCLUDES 30
1 077907 SHROUD EDGE
2 011868 EZ CAM SWITCH
1 011504 LEGEND SHEAR/START/NOTCH
1 011503 LEGEND PUNCH/START/TOOL
1 011862 E-STOP OPERATOR - INCLUDES 9
1 011500 LEGEND E-STOP
5 011872 MOUNTING ADAPTER
2 011878 KNOB FOR RUN/JOG SWITCH
1 004526 RUN JOG LEGEND
1 011502 LEGEND JOG/RUN/PROBE
1 011509 LEGEND START
1 011884 JOG BUTTON ASS'Y INC. 9 & 15
6 011874 CONTACT ELEMENT - N.O.
3 011867 CONTACT M22-K01 - N.C.
1 011879 START BUTTON
2
2 004086 MICRO SWITCH MOUNT
2 562112 LIMIT SWITCH
4 073450 M4 X 16MM SHCS
2 080061 STROKE ADJUSTMENT HANDLE
1 011912 GROUND WIRE ASS'Y
2 220020 M6 X 16MM BHCS
2 073206 M6 HEX NUT
1 562040 WIRE CABLE CLAMP
1 660477 18/18 CABLE
ITEM QTY. PART # DESCRIPTION
004087 POINTER
27
28
29
30
31
32
33
1 033178 METER BOSS DO120-135-150
1 221327 M12 X 70MM SHCS
1 004085 SCALE STROKE CONTROL
2 141010 3/16 X 1/2 ROLL PIN
2 213012 M10 BLACK WASHER
2 201240 M10 X 110MM HHCS
(Replaces Old Version)
