Scotchman DO-150-24M - B die Holder, die Spacer & Punch Table

214012
214012
006262
006013
26713
26713
230107
230107
230107
19305
19305
080063
080063
NOTE: 5, 10, 10A, 10B, & 15 are used
on the DO-150 from S/N 1177M and on.
9.2B DIE HOLDER, DIE SPACER & PUNCH TABLE
2 026618 TEE NUT (M10)1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1 026697 GUIDE FINISHED
3 230110 M8 X 20 FSHCS
1 080182 M5 ALLEN WRENCH
1 037107 DO135/150 PUNCH TABLE
2 080063 RS/JIG HANDLE
2 214014 M12 WASHER
1 219060 M10 X 50 FP SET SCREW
1 204220 M10 X 30 HHCS
1
4 113017 1 3/4 OD X 21/32 ID WASHER
2 201640 M16 X 90 HHCS
1 077145 M7.5 X 20 PIN
2 218058 M10 X 45 DP SS
1 037105 DO135/150 DIE HOLDER
1
1
ITEM QTY. PART # DESCRIPTION
221420 M16 X 50 SHCS
080424 PUNCH BOLSTER
10A 1
10B 1
037110 2" DIE INSERT
037115 2-1/2" DIE INSERT
037120 3" DIE INSERT
