4.4 ELECTRICAL REQUIREMENTS
► CAUTION: TO PREVENT DAMAGE TO THE MOTOR AND DANGER TO THE OPERATOR,
ALL ELECTRICAL CONNECTIONS MUST BE MADE BY A LICENSED ELECTRICIAN.
All machines are wired for three phase electrical power unless otherwise specified by customer.
To insure satisfactory machine performance, the supply voltage should be (+ or -) 10% of the motor
voltage rating.
Check the motor data tag for full load current requirements.
The electrical diagram for the machine is inside the cover of the control box.
THE DIAGRAM IS ALSO IN SECTION 11 AT THE END OF THIS MANUAL.
For electrical supply lines ten feet (3 m) or shorter, we recommend at least 12 and preferably, 10 gauge
wire. For longer supply lines, use at least 10 gauge and preferably, 8 gauge. We do not recommend supply
lines longer than twenty five feet (7.5 m).
POWER REQUIREMENTS:
Motor frame: 3 PH = 215-TC 1 PH = 215TC
MOTOR VOLTAGE FULL LOAD CURRENT
208 31
230 29.6
460 14.8
575 12
230 (Single phase) 40
Motor power rating: 10hp Speed 1,740 RPM
KVA power rating: 7.9 KVA at 230 Volts Frequency 60 HZ.
Starting Current: 210% Full Load
PAGE 15
