Scotchman DO-150-24M - Punch Assembly; A Punch Straps, Punch Ram and Guide

PAGE 90
9.2 PUNCH ASSEMBLY
9.2A PUNCH STRAPS, PUNCH RAM AND GUIDE
1 see 6A STRAP 1
2
3
4
6
7*
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1 see 6A STRAP
4 080192 2.505 BRASS WASHER
1
033205 SHEAR BEAM BUSHING
4
1
016625 2 1/2" SNAP RING
1
080205 LOWER PUNCH PIN (5 & 7 same)
1
1
033178 METER BOSS DO120/135
1
221327 M12 X 70 SHCS
1
203450 M12 X 130 HHCS
1
210014 M12 JAM NUT
1
PUNCH RAM
8
010239
PUNCH RAM W/INSERT
INCLUDES: 12, 14, 15, 16, 17, 18, 19 & 20.
2
080211 3-1/2" PUNCH HOLDER
1
221120 M8 X 25 SHCS
1
141010 3/16 X 1/2 ROLL PIN
3
080133 INSERT W/KEY INC. 16, 17 & 18
1
004123 1/4" KEY (ALL KEY PUNCH)
4
243101 M6 X 13.5 OAL GOLD ZERK
1
080210 GUIDE BLOCK (see 13)
1
221315 M12 X 40 SHCS
2
080215 #40 JAM NUT
033273 PUNCH COVER PAINTED
224205 M10 X 16MM WLCS
ITEM QTY. PART # DESCRIPTION
3A
1
080199 PUNCH LINK KIT INC. 1, 2, & 3
6A
2
080173 KIT INCLUDES 4, 5, 6 & 19
see 13
5* 080205 LOWER PUNCH PIN (5 & 7 same) 2
* The same pin is used in upper and lower locations
