Scotchman DO-150-24M - Electrical Unit

9.10 ELECTRICAL UNIT
PAGE 110
013220 - Assy
19121
Older machines used a 3 amp primary fuse and
(two) 5 amp secondary fuses. Make sure to replace
fuse with one that has the same amp rating.
*
1 011861 TRANSFORMER-250VA1
2
3
4
5
6
7
8
9
1 011933 1-1/2 AMP PRIMARY FUSE
2 2 AMP SECONDARY FUSE
1 011856 DISCONNECT SWITCH
1 011976 3 PH CONTACTOR DILM 32-10
1 OVERLOAD MOUNTING BASE
1 011997 (230V 1 PH) ZB65-57 OVERLOAD
1
013221 (230V) ZB32-32 OVERLOAD
1 N/A TERMINAL STRIP
ITEM QTY. PART # DESCRIPTION
011835
1 011977 1 PH CONTACTOR DILM 655A
1 013217 (460V) ZB32-16 OVERLOAD
1
550065 OPTIONALBACK GAUGE RELAY
7A
7B
N/A
033221 DO 120 CONTROL BOX ASS'Y110
2A*
3A*
011852 3 AMP PRIMARY FUSE
011853
5 AMP N/A: USE GRAINGER
PART # 6F118
1
2
