SCOTT DRX 2002 User Manual

GB - 1
Contents ACCessoRIes
Mounting sleeve
(already mounted
on the unit)
Mounting bolt
Outer trim frame
Brackets (2x)
(already mounted
on the unit)
ISO wire connector
Bolt rubber
Screws: M5x6(4x)
M2,6x5 (4x)
(already mounted
on the unit)
Remote control User manual
ACCESSORIES .................................................................................... 1
SAFETY PRECAUTIONS ..................................................................... 2
INSTALLATION ..................................................................................3-5
MAINTENANCE .................................................................................... 6
PANEL CONTROL ................................................................................7
REMOTE CONTROL ............................................................................ 8
BASIC OPERATION ............................................................................. 9
TUNER ................................................................................................10
DVD/VCD PLAYBACK ........................................................................ 11
CD PLAYBACK ................................................................................... 12
MP3/MPEG4 FILES/JPEG FILES ON A DISC/USB
DEVICE OR SD/MMC CARD .........................................................12-13
ADVANCED PLAYBACK FUNCTIONS .............................................. 14
AUX IN FUNCTION ............................................................................. 14
SYSTEM SETUP ...........................................................................15-16
DVD SETUP ...................................................................................17-19
INFORMATION ON DISC COMPATIBILITY ....................................... 20
TROUBLESHOOTING GUIDE ............................................................ 21
TECHNICAL SPECIFICATIONS .........................................................22

SCOTT DRX 2002 Specifications

Power

power supply	12V DC (11V-16V allowable)
music power output	40W x 4
RMS power output	25W x 4

Display

display size	7” (diagonal), 16:9
resolution	480 x 234
view angle	130 ˚ (Horizontal), 105 ˚ (Vertical)

Radio

FM frequency range	87.5 – 108.0MHz
FM IF range	10.7MHz
FM usable sensitivity	8 dBμ

Weight and Dimensions

weight	3 Kg
dimensions	178 x 100 x 164mm
