GB - 3
Wiring Diagram
USB SLOT
Fuse 15A
ISO Connector
Green
with
Black
Stripe
White
with
Black
Stripe
Gray
with
Black
Stripe
Purple
with
Black
Stripe
CAMERA IN (Yellow)
VIDEO IN (Yellow)
VIDEO OUT 2 (Yellow)
REAR AUDIO OUT-R (Red)
REAR AUDIO OUT-L (White)
AUDIO IN-L (White)
AUDIO IN-R (Red)
VIDEO OUT 1 (Yellow)
Antenna
WIRE TO ACTIVATE REVERSING
CAMERA (Pink)
+
PARKING BRAKE WIRE(Green) -
InstALLAtIon

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SCOTT DRX 2002 and is the answer not in the manual?

SCOTT DRX 2002 Specifications

Power IconPower
power supply12V DC (11V-16V allowable)
music power output40W x 4
RMS power output25W x 4
Display IconDisplay
display size7” (diagonal), 16:9
resolution480 x 234
view angle130 ˚ (Horizontal), 105 ˚ (Vertical)
Radio IconRadio
FM frequency range87.5 – 108.0MHz
FM IF range10.7MHz
FM usable sensitivity8 dBμ
Weight and Dimensions IconWeight and Dimensions
weight3 Kg
dimensions178 x 100 x 164mm
