P/N 595224-01 Rev E 7/12Page 24 of 32
FLASHLIGHT ACCESSORY
An external ashlight accessory is available. The STREAMLIGHT TLR-1 ashlight
mounts on a rail on the top of the camera housing. The ashlight projects a beam of
light in whatever direction the camera is pointed. The ashlight can be removed for
independent operation. The ashlight uses its own battery and is not recharged along
with the camera. The Picatinny mounting rail (MIL-STD-1913) will also accommodate
other accessories. Refer to the User Instructions provided with the ashlight for details
of mounting, use, and maintenance. See FIGURE 16.
LANYARD ACCESSORY
An optional heavy duty three foot long retractable lanyard (P/N 201021-01) is equipped
with a clip on one end. The split ring attachment point may be installed in any of the
three ring loops on the handle. See FIGURE 17.
FIGURE 16
FIGURE 17
SPLIT
RING
RING
LOOPS
