SET-UP OF OTHER SHOCK MODELS
SCOTT strongly recommends using only the FOX Nude (FOX CTD shock) with the
Genius bike, as we designed both parts for a perfect matching combination with a
linear suspension rate.
Also on those shock models the SAG should be 14/12.5mm.
Other Shock Models on Genius
If you want to use a different rear shock model than the one originally on the bike,
please make sure that the shock will not in any position hit the frame and cause a
damage to the frame.
Please follow the instruction below:
- Please make sure that the rear shock or its accessory parts do not touch the frame
when mounting or suspending.
- For doing so release the air/remove the coil, install the shock and compress the
shock completely.
- If the shock touches the frame while doing so, do not use this shock in order to
avoid damage to frame, swingarm or shock.
HEADSET OPTIONS
Genius features a tapered headset and fork
steerer system to match with semi-integrated
headsets of the “50-61”mm range with ID of
Headtube of 44.0mm on top and 54.9mm on
the lower end.
Ritchey WCS Carbon Zero Tapered PF 50-61mm 18mm UD PRD 13636
Ritchey PRO Tapered PF 50-61mm 12.9mm PRD 13640
It is also possible to use forks with a standard 1 1/8” steerer tube when using a
reducer headset such as e.g.
Ritchey WCS Carbon Zero Tapered PF 50-61mm 18mm UD for 1 1/18" fork PRD 14860
BOTTOM BRACKET (BB) ON GENIUS
All frames of Genius (carbon and alloy) have a BB shell for BB92PF standard.
This matches to several bearing and crankset models of Shimano, SRAM, FSA
and others.
Please note that you do not need anymore a spacer on the right side of the
bearing cup between frame housing and bearing cup.
