SCOTT Genius 2015 User Manual

02
GENIUS | BIKE OWNER’S MANUAL 2015 BIKE OWNER’S MANUAL 2015 | GENIUS
03
www.scott-sports.com
ENGLISH ENGLISH
The Genius should be adjusted exactly to the current rider for
reaching maximum safety and fun while riding.
All adjustments should be done at your local SCOTT dealer or
following this manual’s instructions.
In order to avoid technical problems or any harm please contact in
case of doubts your authorized SCOTT dealer.
CONTENT
Genius Concept. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 04
Geometry/Technical Data Genius 650B/27.5”. . . . . . . . . . . . . . . . . . . . . . . . . 05
Geometry/Technical Data Genius 29”. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06
TC Shock Technology/Twinloc Levers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 07
Assembly of the Remote Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
FOX Nude Shock and Twinloc Remote Control Lever . . . . . . . . . . . . . . . . . . . . . 11
Basic Set-Up of the Twinloc Remote Control of FOX Nude Shock . . . . . . . . . . . . . 12
Basic Set-Up of the Twinloc Remote Control of Fox CTD Shock . . . . . . . . . . . . . . 14
Recommended Tools for the Shock Set-Up . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Set-Up Genius with FOX Nude or FOX CTD Shock. . . . . . . . . . . . . . . . . . . . . . .15
SAG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Set-Up of Rebound FOX Nude or FOX CTD Shock. . . . . . . . . . . . . . . . . . . . . . .16
Set-Up of Other Shock Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Headset Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Bottom Bracket (BB) on Genius . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Adjustable BB Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Front Derailleur (FD) Mounting Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Chainguide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Genius Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Adjustment of Seatpost-Height. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Replaceable Dropout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Rear Disc Brake Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Front Fork Set-Up/Change of Front Fork. . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Pivot Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

SCOTT Genius 2015 Specifications

General

Wheel Size	27.5"
Handlebar	Syncros FL1.5 Tbar, Alloy 7050 D.B., T shape Flat, 9°, 700mm
Seatpost	Syncros FL1.5, 31.6mm
Saddle	Syncros XR1.5, Titanium rails
Model Year	2015
Suspension	Full Suspension
Groupset	Shimano XT
Brakes	Shimano XT
Shifters	Shimano XT
Front Derailleur	Shimano XT
Rear Derailleur	Shimano XT
Crankset	Shimano XT
Tires	Schwalbe Nobby Nic
Category	Mountain
Frame Material	Carbon
Frame	Genius Carbon HMX
