SCOTT PRO-PAK User Manual

PRO-PAK
5
Weight of Pro-Pak
with Cylinder
(kg)
Cylinders Water
Capacity
(litres)
Charging
Pressure
(bar)
Free air
Volume
(litres)
Nominal
Duration
(min)
Warning
Period
(min)
Total
Duration
(min)
Cylinder
Charged
Weight
(kg)
Single Duo
CYL-1200
6.0 200 1200 22 8 30 8.8 12.0
-
CYL-HWG-
1200
6.0 207 1200 22 8 30 7.2 10.4
-
CYL-FWC-
1300
4.7 300 1300 25 7 32 5.0 8.2
-
CYL-1640
6.0 300 1640 33 8 41 12.5 15.7
-
CYL-HWG-
1640
6.0 300 1640 33 8 41 10.0 13.2
-
CYL-FWC-
1640
6.0 300 1640 33 8 41 6.3 9.5 16.0
CYL-1800
9.0 200 1800 33 12 45 13.0 16.2
-
CYL-HWG-
1800
9.0 207 1800 33 12 45 11.2 14.4
-
CYL-FWC-
1800
9.0 207 1800 33 12 45 6.75 9.95 18.0
CYL-FWC-
1860
6.8 300 1860 37 9 46 6.75 9.95 18.0
CYL-FWC-
2460
9.0 300 2460 50 12 62 8.8 12.0
-
Note: Only cylinders in the shaded areas (above) are suitable for use with Pro-Pak Duo in
the twin-cylinder configuration. The total apparatus weight must not exceed 18 kg when fully-
charged; (ref: EN 137, Clause 5.4 and AS/NZS1716 : 2003).
Table 3: Cylinders approved for use with Pro-Pak apparatus
Table 4 identifies the cylinder material code and cylinder specification.
Code Material Specification
No Code Steel (e.g.: CYL-1200)
CE Marked (EU)
Work Cover (Australia & New Zealand)
HWG Hoop Wrapped Glass Fibre (e.g.: CYL-HWG-1200)
HSE-AL-HW1 (EU)
Work Cover (Australia & New Zealand)
FWC Fully Wrapped Carbon (e.g.: CYL-FWC-1300)
CE Marked (EU)
Work Cover (Australia & New Zealand)
Table 4: Cylinder Codes and Specifications
Durations are nominal and based on an Average Wearer Consumption Rate of 40 L/min and
are for fully charged cylinders.
Cylinder Free Air Capacity
Total Duration =
Average Wearer Consumption Rate
Nominal Duration = Total Duration minus the Warning Period.
Whistle Operating Pressure
Warning Period =
Average Wearer Consumption Rate
