Astra 600 - Page 11
System WWiring
15-Pin Main Harness
Pin 1 BLUE/WHITE: Passenger Unlock output (-) 500mA. Connect to an optional relay to unlock the
passenger doors for two-stage unlock (see Two Stage Door Lock Diagrams).
Pin 2 GRAY WIRE: Auxiliary 1 Output (+/–) 7A. Connect to an optional feature such as trunk release, etc.
Pin 3 BLACK/YELLOW WIRE: Auxiliary 3 Output (-) 500mA. Connect to a relay or module for an optional
feature such as power window activation or remote start, etc.
Pin 4 BLACK/WHITE WIRE: Dome Light Relay Output (+/–) 7A. Connect to the wire that activates the
vehicle’s dome light, usually the door pin switch wire. NOTE: The dome light output may usually
connected to the same wire used for the door trigger input (See GREEN and VIOLET door trigger wires).
Pin 5 RED WIRE: +12V Battery Input (15A Fuse). The Red wire must be connected to a clean source of
continuous +12V power.
Pin 6 BROWN WIRE: Siren Output (+) 3A. The BROWN wire must connect to the siren’s red wire. The
BLACK siren wire must be grounded.
Pin 7 VIOLET WIRE: Positive door trigger Input (+). Connect to the door switch circuit wire that shows
+12V when the door is open. This type of door circuit is usually found on Ford
vehicles.
Pin 8 BLACK WIRE: Ground Input (-). The BLACK wire must connect to a solid chassis ground. Clean away
any paint or dirt to insure the best possible ground.
Pin 9 WHITE WIRE: Parking Light Output (+/–) 7A. The WHITE wire must connect to the circuit that shows
+12V or ground when only the parking lights are on. For parking light circuits exceeding 7 amps, a relay
is required. For vehicle’s with independent left and right parking light circuits, diodes must be used to
keep the circuits separate. NOTE: Do not connect the WHITE wire to the vehicle’s headlight circuit.
Pin 10 GREEN WIRE: Negative door trigger Input (-). Connect to the door switch circuit wire that shows
ground when the door is open.
Pin 11 YELLOW WIRE: +12V Ignition Input. The YELLOW wire must connect to a main ignition wire at the
ignition harness. This wire must show +12V when the ignition is on.
Pin 12 ORANGE WIRE: Armed Output (–) 500mA. The ORANGE wire provides a ground output while armed
to activate an optional circuit defeat relay or other device such as a power window control module.
Pin 13 WHITE/RED WIRE: Auxiliary 2 Output (-) 500mA. Connect to a relay or module for an optional
feature such as power window activation or remote start, etc.
Pin 14 BLUE WIRE: Trunk/Hood trigger Input (-). Connect the BLUE wire to the trunk and/or optional hood
pin switches. The switch must provide a ground output when opened.
Pin 15 BROWN/WHITE WIRE: Horn Output (-) 500mA. Connect to an optional relay to activate the
vehicle’s horn when the alarm is triggered.
5-Pin Door Lock Harness
Pin 1 WHITE WIRE: Lock Relay Pin 87a (Normally Closed).
Pin 2 GREEN WIRE: Lock Relay Pin 30 (Common).
Pin 3 BLUE WIRE: Unlock Relay Pin 30 (Common).
Pin 4 BROWN WIRE: Unlock Relay Pin 87a (Normally Closed).
Pin 5 VIOLET WIRE: Lock/Unlock Relays Pin 87 (Normally Open) [10A Fuse].
