SDEC D Series - Page 120

Operation and Maintenance Manual SC9DF Electronically Controlled Diesel Engine for Agricultural Equipment
57
34 P0342 Cam Sensor No Pulse 12
35 P0385 Crank & Cam Sensor No Pulse 13
36 P0503 Vehicle Speed Sensor Frequency Too High 21
37 P0502 Vehicle Speed Sensor Input Open / Short 21
38 P0501 Vehicle Speed Sensor Signal Invalid 21
39 P1681 Exhaust Brake MV1 Output Open Load/Short to GND 28
40 P1682 Exhaust Brake MV1 Output Short to BATT 28
41 P2148 COM1 output short to BATT TWV1or3or5 output short to BATT 57
42 P2147 COM1 output short to GND TWV1or3or5 output short to GND 57
43 P2146
COM1 output open load Both TWV1 and TWV3 and TWV5
open load
57
44 P2151 COM2 output short to BATT TWV2or4or6 output short to BATT 58
45 P2150 COM2 output short to GND TWV2or4or6 output short to GND 58
46 P2149
COM2 output open load Both TWV2 and TWV4 and TWV6
open load
58
47 P0201 TWV1 output open load Injector coil open 51
48 P0205 TWV2 output open load Injector coil open 55
49 P0203 TWV3 output open load Injector coil open 53
50 P0206 TWV4 output open load Injector coil open 56
51 P0202 TWV5 output open load Injector coil open 52
52 P0204 TWV6 output open load Injector coil open 54
53 P0611 Capacitor charge-up circuit malfunction (insufficient charge) 59
54 P0200 Capacitor charge-up circuit malfunction (excessive charge) 59
55 P0629 SCV(+) output short to BATT; SCV(-) output short to BATT 74
56 P0627
SCV(+) output Open Load/short to GND ; SCV(-) output Open
Load/short to GND ; SCV coil open
75
56 P0627
SCV(+) output Open Load/short to GND ; SCV(-) output Open
Load/short to GND ; SCV coil open
75
57 P1190 Supply pump control valve (suction control valve) stuck 75
58 P0093 Common Rail Pressure Sensor Performance Invalid included fuel leak 78
59 P2293 Supply pump protection 79
60 P1217 Supply pump exchange 79
61 P1218 Supply pump malfunction (insufficient flow) 77
62 P1219 pressure limiter activated 77
63 P1089 Common rail pressure exceeds upper limit 69
64 P0088 Common rail pressure exceeds hi upper limit 68
65 P0301 Cylinder 1 fuel system falure 61
