Operation and Maintenance Manual SC9DF Electronically Controlled Diesel Engine for Agricultural Equipment
11
2.4 Main Specifications and Parameters
2.4.1 Main specifications
Model
SC9DF270G3 SC9DF280G3 SC9DF290G3 SC9DF300G3 SC9DF320G33 SC9DF340G3
Type on line, 4-stroke, water cooled, single cylinder two-valve, direct injection engine
Displacement (L) 8.8
Bore (mm) 114
stroke (mm) 144
Number of cylinders 6
Aspiration turbocharged and charge air cooled (air-to-air intercooler)
Compression ratio 18:1
Fuel injection equipment High-pressure common rail
Combustor type
ω type
Ignition order (from free end) 1-5-3-6-2-4
Crankshaft rotation direction
(facing flywheel end)
Counterclockwise
Starting Electric
Rated power (kW)
169.5 177 184 191.5 206 221
Rated net power (kW)
198 204 211 218 233 248
Rated speed (r/min) 2200 2200 2200 2200 2200 2200
Net weight (kg) 680-780, 880-980 (with an oil pan having function of engine support)
Main application tractor
Dim.
Length (mm) 1371
Width (mm)
812
Height (mm)
1372 (with air filter)
Note: The listed engine performance data are obtained at the standard test conditions: ambient temperature is 25℃,
relative humidity 30% and barometric pressure 100 kPa.
