13
This document is the property of SDMO Industries.
Any communication, reproduction, publication, even partial, is forbidden, except with the written authorisation of the owner.
8.4 Basic settings screen
The parameters available in the "Basic settings" screen are listed below.
nominal voltage phase/neutral () from 80V to 480V (in increments of 1V) 230
nominal voltage phase/phase () from 80V to 600V (in increments of 1V) 400
nominal frequency 1 = 50Hz, 2 = 60Hz 1
connection type 1=1Ph+N, 2=2Ph+N, 3=3Ph, 4=3Ph+N 4
unit format 1=Bar and °C, 2=PSI and °F 1
zero consumption mode from 0 to 360min (in increments of 1min) 0
nominal current from 1A to 5000A (in increments of 1A) 50
primary CT from 1A to 5000A 50
nominal speed from 100 to 4000rpm (in increments of 1rpm)
nominal power from 1 to 3000kW (in increments of 1kW) 100
automatic screen scrolling 1 = active, 2 = inactive 1
automatic voltage and frequency detection 1= inactive, 2=active 1
fuel solenoid valve type 1=diesel, 2=gas 1
priority mode selection
1=
1
() B01 only displays if B04 is set to 1 B02 only displays if B04 is set to 2, 3 or 4
8.5 Engine safety features and parameters screen
The parameters available in the "Engine safety features and parameters" screen are listed below.
preheating delay from 0 to 600s (in increments of 1s) 10
starter attempt delay from 0 to 60s (in increments of 1s) 5
cooling delay from 0 to 3600s (in increments of 1s) 180
oil pressure fault threshold from 0 to 10Bar 1 (3s)
coolant temperature fault threshold 0 to 150°C 90 ( 5s)
min. battery voltage threshold from 8 to 40V 11.5 (3min)
maintenance alarm threshold from 0 to 10000h 9999
starter cut off due to oil pressure 1= inactive, 2=active 1
stabilisation delay from 1 to 300s 5
low fuel level anomaly threshold from 0 to 80% 20 (10s)
preheating maintenance delay () from 0 to 3600s 30
automatic start when battery voltage at minimum 1 = active, 2 = inactive 1
min. battery voltage recharge delay 1 to 240min 60
low fuel level anomaly 1=alarm; 2=fault 1
() when the generating set is started up (used for cold countries)
Note: certain values are associated with a fixed delay, given in brackets.
8.6 Alternator safety features screen
The parameters available in the "Alternator safety features" screen are listed below.
max. voltage fault from G02 to 200% (increments of 1%) () 110 (3s)
min. voltage fault from 0 to G01% (increments of 1%) () 70 (3s)
maximum frequency fault from to G04 to 130% (increments of 1%) () 110 (3s)
min. frequency fault from 0 to G03% (increments of 1%) () 85 (3s)
short circuit fault from 100 to 500% (increments of 1%) () 150 (G06)
short circuit delay from 0 to 10s (in increments of 1s) 0
overload alarm from 70 to 130% (increments of 1%) () 110 (G08)
overload delay from 0 to 300s (increments of 1s) 10
Note: certain values are associated with a fixed or variable delay, given in brackets.
(
) in percentage of nominal U (parameter B01 or B02)
(
) in percentage of nominal F (parameter B03)
(
) in percentage of nominal I (parameter B09)
(
) in percentage of nominal P (parameter B12)
