SDMO APM303 User Manual

18
This document is the property of SDMO Industries.
Any communication, reproduction, publication, even partial, is forbidden, except with the written authorisation of the owner.
10 Technical specifications
Control unit
. dimensions 118 x 108 x 40 (length x height x depth)
. protection index IP54 on front panel, IP20 on rear, connectors side
. weight without packaging 200g
. cut-out for assembly 94 x 94 minimum (+/-1 mm)
. tightening torque for assembly from 15 to 20cNm
Environment
. operating temperature -20°C to +70°C
. storage temperature -30°C to +80°C
. humidity 95% at 45°C, 70% at 50°C, 50% at 60°C
Power supply
.
T01
terminals (0 V battery) and
T03
(+ battery)
(on 3-pin connector)
. nominal voltage 12Vdc or 24Vdc
. voltage range from 8 to 36Vdc
Binary inputs
. 6 binary inputs, terminals
T10
,
T11
,
T12
,
T13
,
T14
and
T15
(on 12-pin connector)
. not isolated
. connected to 0Vdc
Emergency stop input
. 1 binary input, terminal
T04
(on 12-pin connector)
. not isolated
. connected to + battery
Binary outputs
. 5 binary outputs, terminals
T05
,
T06
,
T07
,
T08
,
T09
(on 12-pin connector)
. not isolated
. operating range from 8 to 36Vdc
. flyback diode required for inductive load
. safety feature protecting against: short-circuit, overload,
overvoltage peaks
. not protected against polarity inversion
Analog inputs
3 analog inputs, terminals
T13
,
T14
,
T15
(on 12-pin connector)
. not isolated
. measurement range: from 0 to 2500

Voltage measurement
. . 1 input, terminals
T20
,
T21
,
T22
,
T23
(on 7-pin connector)
with 1 of the 2 pins not used
(see section 10 for possible connections)
. true RMS value
. voltage range: from 80 to 480Vac between phases
from 50 to 277Vac between phase and neutral
. not isolated
Frequency measurement
. 1 input, terminal
T21
(phase 1)
(on 7-pin connector)
. measurement on the fundamental
Current measurement
. . 1 input, terminals
T16
,
T17
,
T18
,
T19
(on 4-pin connector)
. true RMS value
. measurement range: from 100mA to 6A (secondary CT)
. not isolated
Charging alternator excitation
. 1 binary input/output, terminal
T02
(on 3-pin connector)
. excitation current: 100mA
Communication
. USB
(on B type connector)
. device type
. on the module
RS485 interface
1 input/output, 3 terminals (
A
,
COM
,
B
)
(on 3-pin connector)
RS485 type
. on the module
