SDMO R570U - Page 17

7 Battery charge alternator 9 Main circuit breaker
8 Starter batteries 10 Connection termination box
Figure 2.1 (continued): General description of the generating set
11 Filling with fuel 13 External fuel supply combined tap (optional)
12 Oil filters 14 Circuit breaker
Figure 2.1 (continued): General description of the generating set
7
8
10
9
11
12
13
14
15/297
