2.12
SECTION 2 • GENERAL BOAT ARRANGEMENT
220 Select
INSERTING THE REMOVABLE STERN ANCHOR LIGHT
(FIG. 2.12.2)
SCREW IN TYPE
CONNECTOR
ANCHOR LIGHT
MAST
COMPRESSION TYPE
CONNECTOR
DECK ANCHOR
LIGHT FITTING
NAVIGATION AND A NCHOR LIGHTS
(FIG. 2.12.1)
RED SIDE LIGHT
(VISIBLE 2 NAUTICAL MILES)
GREEN SIDE LIGHT
(VISIBLE 2 NAUTICAL MILES)
360
0
WHITE LIGHT
(VISIBLE 2 NAUTICAL MILES)
