Sea Ray 220 Select - Navigation and Anchor Lights; Swim Platform and Ladder

7.5
SECTION 7 • OPTIONS & ACCESSORIES
220 Select
STERN LIGHT
(FIG. 7.5.1)
SCREW IN TYPE
CONNECTOR
ANCHOR LIGHT
MAST
COMPRESSION
TYPE CONNECTOR
RED/GREEN BOW
NAVIGATION LIGHT
12. WATER SPORT TOWER (OPTIONAL)
If equipped, the water sport tower provides a raised
attach point for the ski rope. The high attach point
enables the skier to perform a wide variety of skills
not capable with the lower transom attach point.
TO AVOID RISK OF SERIOUS INJURY OR DEATH SHUT
OFF ENGINE WHEN NEAR SWIMMERS OR PRIOR TO
USING SWIM PLATFORM AND BOARDING LADDER.
! DANGER
10. NAVIGATION AND ANCHOR LIGHTS
Navigation lights MUST be on while underway from
sunset to sunrise or in conditions of reduced
visibility. “Underway” means the boat is not docked
or at anchor. Trolling or drifting with engine off is
considered “underway” and navigation lights must
be used.
If you are anchored in open water, i.e. where other
boats can approach yours, you must display your
anchor light (Figure 2.10.1): a white light that can
be seen from all possible directions, i.e. 360
degrees.
Read the “Federal Requirements and Safety Tips
for Recreational Boats” provided in your kit.
11. SWIM PLATFORM AND LADDER
The swim ladder is located on the stbd side of the
swim platform. Unfold the ladder and drop into the
water to assist swimmers in boarding the vessel.
SWIM PLATFORM LADDER
(FIG. 7.5.2)
LADDER (STOWED)
WATER SPORT TOWER (OPTIONAL)
(FIG. 7.5.3)
