Sea Ray 220 Select - Installation Tips

7.8
SECTION 7 • OPTIONS & ACCESSORIES
220 Select
For your safety, decide which canvas pieces you
want to remove or install before you leave the boat
slip or off-load your boat from the trailer into the
water. Removing or installing canvas on the water
can be difficult since rough water or wakes can
cause you or your passengers to lose their balance
while attempting canvas removal or installation.
For safety and ease of installation and removal of
canvas, use at least two people. Know which canvas
piece(s) that you are to install or remove.
! DANGER
Exhaust fumes from engines contain deadly carbon
monoxide gas (CO). Boats enclosed with canvas or
with poor ventilation are most likely to collect fumes.
CO sickness symptoms include headache, nausea
and dizziness. Do not mistake these symptoms for
sea sickness.
Ventilate boat. See Section 1.4, Carbon Monoxide,
for more details.
The standard canvas set for the 220 Select consists
of a bimini top with boot and a cockpit cover/tonneau
cover.
The following canvas options are available.
Bimini Aft Curtain Side Curtains
Canvas Storage Bag Front Curtain
A. INSTALLATION TIPS
• Zippers: Zippers are located on each canvas
piece. Make sure canvas is centered over the
metal canvas support rods (bows). When
attaching any canvas piece, zip the zippers only
partially. This helps to hold the piece in place
and relieves tension, helping the other sides zip
or snap easier. After all the sides of the piece
are snapped in place, finish zipping all the
zippers. This will ensure a tight fit.
• Adjustable Support Rods: Adjustable support
rods are located on the Convertible and Bimini
Top. There is an outside tube and an inside
tube. Push in the button to adjust for longer or
shorter rod lengths.
• Windshield Snapless Extrusion: The snapless
extrusion eliminates the need for snaps and
provides a water barrier at the windshield frame
! DANGER
In rainy weather and/or cold weather, fresh air must
circulate through boat to avoid carbon monoxide
poisoning.
See Section 1.4, Carbon Monoxide, for more details.
COCKPIT COVER
(FIG.7.7.1)
BIMINI TOP
(FIG.7.7.2)
SUNBRELLA
®
BIMINI TOP
BIMINI AFT
CURTAIN
(OPTIONAL)
SIDE CURTAINS
(OPTIONAL)
FRONT
CURTAINS
(OPTIONAL)
