Sea Ray 220 Select - Bow Seating (Optional); Aft Seat; Control Station Seating; Volt Receptacle

7.2
SECTION 7 • OPTIONS & ACCESSORIES
220 Select
2. BOW SEATING (OPTIONAL)
Bow seating can be converted into full area
cushioned seating by placing the inserts into the
open area of the bow and placing the appropriate
cushions in place. The inserts are stowed in the stbd
bow storage and the cushions in the port bow
storage compartment.
3. AFT SEAT
The port single aft seat serves as an entryway for
boarding and disembarking the vessel. Remove the
seat cushion from the seat to expose the non-slip
surface for entry. The cushion can be stowed in the
port hull storage cutout when not in use. When
replacing the cushion ensure that the seat post is
secured into the seat bottom receptor which will keep
the cushion from dislodging while underway.
CONVERTABLE BOW SEATING
(FIG.7.2.1)
STBD BOW
STORAGE
PORT BOW
STORAGE
AFT JUMP SEAT
(FIG.7.2.2)
4. CONTROL STATION SEATING
The control station seat and companion seat feature
a thigh-rise cushion which can be lifted out of the
way to accomodate standing while maneuvering the
vessel for docking and/or anchoring.
5. 12 VOLT RECEPTACLE
Your Sea Ray
®
is equipped with a 12 volt accessory
receptacle located in the starboard hull storage
HELM SEAT
(FIG.7.2.4)
REMOVABLE SEAT CUSHION
(FIG.7.2.3)
! DANGER
DO NOT STAND WHILE OPERATING UNDERWAY
Use the thigh-rise feature only while docking,
anchoring and/or while vessel is not under power.
12VDC-15A MAX
12 VOLT RECEPTACLE
(FIG.7.2.5)
STBD COCKPIT
SIDE PANEL
STORAGE
