Seagate CD72LWH - Figure 4. Internal Drive-Dimensions; Figure 5. Internal DDS Drive with Rails-Dimensions

8
DAT 72/DDS-4 Product Manual
41.3 mm
(1.63 in)
101.6 mm
(4.00 in)
101.6 mm
(4.00 in)
94.0 mm
(3.70 in)
3.8 mm (0.15 in)
13.0 mm (0.51 in)
2 places
5.0 mm (0.196 in)
2 places
90.0 mm
(3.54 in)
2 places
70.0 mm
(2.75 in)
6.0 mm
(0.24 in)
31.0 mm
(1.22 in)
146.0 mm
(5.75 in)
41.2 mm
(1.62 in)
60.0 mm
(2.36 in)
2 places
21.0 mm (0.83 in)
2 places
Side View
Bottom View
M3.0 x 4 deep min.
(10 places)
M3.0 x 4 deep min.
(4 places)
Note: Tolerance for all dimensions is 0.25mm (0.01 in)
Figure 4. Internal Drive—Dimensions
41.3 mm
(1.63 in)
31.5 mm (1.24 in)
146 mm
(5.75 in)
174.6 mm
(6.87 in)
79.4 mm
(3.13 in)
47.6 mm
(1.87 in)
21.8 mm (0.86 in)
9.9 mm (0.39 in)
16-M3
41.2 mm
(1.62 in)
139.7 mm (5.50 in)
149.1 mm (5.87 in)
Side View
Bottom View
Note: Tolerance for all dimensions is 0.25mm (0.01 in)
Figure 5. Internal DDS Drive with Rails—Dimensions
