Drive operation and maintenance
29
Write protected
Write enabled
Figure 18. Write-Protect Tab on a DDS Cartridge
LED Codes
As shown in Figure 19, the front panel of the DDS drive contains three LEDs that
provide information about both normal and error conditions. The external drive also
includes a green power-on LED on the front panel.
Clean
LED
(green)
Media
LED
(green)
Eject
Button
Drive
LED
(amber)
Figure 19. Front Panel of an Internal Drive
(external drive is similar)
